A New lightweight Core

ROHACRYL™ is an exciting new product line from the Performance Foams business line of Evonik Resource Efficiency. Based on acrylate chemistry, this environmentally friendly core material solution is thermally stable and features excellent mechanical performance.

ROHACRYL™ SW foam sheet

Industries

Marine
Sports Equipment
Lifestyle
Subsea
Construction

Overview

ROHACRYL™ SW is a closed cell foam with a fine, homogeneous cell structure that is free of harmful CFC’s. The small cell size makes it possible to keep resin absorption at the surface of the foam core to a strict minimum.

This rigid foam product is ideal for lightweight sandwich construction in a wide variety of applications in industries like sports equipment, lifestyle, marine and subsea, as well as automotive and industrial markets.

Process Benefits

ROHACRYL™ is easy to machine with the ability to cut it quickly and cleanly. The compatibility with automated handling systems due to closed cells and the high processing temperature are a requisite for shorter cycle times.

The result is increased production efficiency from start to finish. ROHACRYL™ is the foam of choice for automated, high-volume production with RTM and infusion processes. It addresses the needs of the whole design and production chain with excellent mechanical properties at low densities, low resin absorption and high process temperatures.

Sustainability

The recyclable raw material base of ROHACRYL™ offers a low carbon footprint and a clean end-of-life solution. Low resin consumption, a leaner design, and short cycle times are additional levers for responsible production in our global environment.

Future-proof your applications for the challenges of a circular economy – without any harmful CFCs!

Grades

60 SW

80 SW

100 SW

Properties

Density

Method: ASTM 1622

60 SW
60kg/m³
3.75lbs/ft³
80 SW
80kg/m³
5.00lbs/ft³
100 SW
100kg/m³
6.25lbs/ft³

Compressive Strength

Method: ASTM 1621

0.80MPa
115psi
1.40MPa
200psi
2.00MPa
290psi

Compressive Modulus

Method: ASTM 1621

40MPa
5,800psi
70MPa
10,150psi
105MPa
15,230psi

Tensile Strength

Method: ASTM D638

1.6MPa
230psi
2.20MPa
320psi
2.79MPa
405psi

Tensile Modulus

Method: ASTM D638

70MPa
10,150psi
98MPa
14,200psi
127MPa
18,400psi

Shear Elongation at Break

Method: ASTM C273

> 6.0%
> 6.0%
> 6.0%

Shear Strength

Method: ASTM C273

0.75MPa
110psi
1.23MPa
175psi
1.70MPa
245psi

Shear Modulus

Method: ASTM C273

25MPa
3,600psi
38MPa
5,500psi
52MPa
7,500psi

Excellent properties

ROHACRYL™ foam in a sandwich lay-up
The unique combination of mechanical strength and stiffness at low densities allows you to build your sandwich design leaner and lighter. Highly isotropic cells, tailored for low resin absorption, offer additional weight saving potential. Rethink your design and watch the weight of your products decrease!
